2017 Optimum OPTImill MF4-B Turret Milling

2017 Optimum OPTImill MF4-B Turret Milling

Dimensions and weights Length (product) approx.2400 mm

Width/depth (product) approx.2160 mm

Height (product) approx.2300 mm

Net weight approx.1260 kg

Equipment

Digital position indicator DPA 31 Plus Drilling/milling head Drill-mill head tilt range vertical ± 45 °Mill head swivel range horizontal ± 90 °Drilling/milling output Max. size milling head 76 mm Max. size shaft milling cutter 25 mm Drilling performance steel (S235JR) 24 mm Continuous drilling performance steel (S235JR) 20 mm Electrical Data Total rated value 3 kW Supply voltage 400 V Mains frequency 50 Hz Milling table horizontal Horizontal milling table length 254 mm Horizontal milling table width 1370 mm Max. clearance vertical spindle - horizontal milling table 405 mm Horizontal milling table T-groove size 16 mm Horizontal milling table T-groove number 3 Horizontal milling table T-groove spacing 63 mm Horizontal milling table max. load bearing capacity 300 kg Cooling lubricant system Coolant pump(s) drive power 90 W Standards and certifications Standard DIN EN 55011 Travel Travel X axis manual 820 mm Travel Y axis manual 410 mm Travel Z axis manual 400 mm Travel X axis automatic 740 mm Travel Y axis automatic 330 mm Travel Z axis automatic 320 mm Vertical spindle Vertical spindle reach from to 0 - 420 mm Vertical spindle spindle chuck ISO 40 DIN 2080 Vertical spindle speed range 60 - 4200 min¯¹Vertical spindle number of gears2Vertical spindle speed control mechanically step less Vertical spindle quill diameter 86 mm Vertical spindle quill stroke 127 mm Vertical spindle quill feed 0.04 / 0.08 / 0.15 mm/rev Vertical spindle milling head travel Y axis 470 mm Vertical spindle drive motor output normal operation 2,2 kW
