Ribon RUR800

Ribon Model RUR800 Cylindrical Grinder

Internal / External Grinder

height of tip: 140 mm swing – Ø: 280 mm width of tip: 800 mm grinding wheel: diameter: 355x 127 x 32 mm max. width of full grinding wheel during punch-grinding: 60 mm max. size total width of grinding wheel set: 70 mm max. sum of single widths: 32 mm grinding wheel speeds infinitely adjustable via planetary gear grinding head: adjustment of grinding head left – right: 90° each max. grinding head hub: 180 mm max hub using hand wheel: 180 mm autom. interval feed: 0,005 – 0,015 mm feed via one revolution of the hand wheel: 1,3 mm feed via one hand wheel unit: 0,005 mm max. diameter adjustment: 0,05 – 3,0 mm diameter adjustment via tipping switch: 0,005 mm diameter adjustment via micro-stop: 0,001 mm headstock spindle: 8 workpiece speeds, adjustable: 35 – 310 rpm spindle cone or inner cone of headstock spindle: MK 4 headstock spindle bore: 24 mm tilting of headstock:
